Z Axis Dovetail Stage SEMC4A-60 With Micrometer Head & Feeding Screw
Z Axis Dovetail Stage SEMC4A-60



Product Number : SEMC4A-60

Table Size 60x60mm
Travel stroke ±9mm
Moving straightness 30μm
Load capacity 19.6N
Weight 0.38Kg
Material Aluminum
Surface treatment Black anodized

The SEMC4A-60 dovetail stage is a compact positioner for use in general purpose motion control applications. It provides a travel range of ±9mm and equipped with eight tapped holes to maximize the mounting options for moving components. The modular design of the SEMC4A-60 allows single stages.

The z axis dovetail stage SEMC4A-60 is suitable for optical instruments, measuring devices, inspection apparatus, semiconductor manufacturing equipment, testing machines, microscopes, handling machine, processing machines, medical equipment, printing, and more.

  • Single Axis : Z Axis Manual Stage
  • Guiding Type : Dovetail Guiding
  • Feeding Mode :Rack and Pinion Type
  • Minimum reading : 0.1mm/Vernier
